[2026] C++ Segmentation Fault: Five Causes and Debugging with GDB, LLDB, and ASan

Related: undefined behavior · another segfault walkthrough: segmentation fault (checklist).

Introduction: “Segmentation fault (core dumped)”

A segmentation fault is a runtime crash: the OS delivers SIGSEGV (Unix) when your process touches memory it must not (typical cases: null, freed, out of range, read-only). This article covers:

• Five major causes
• GDB/LLDB on core dumps
• AddressSanitizer
• Quick reference tables
  Environments: Examples assume GCC/Clang on Linux/macOS; WSL or VS + ASan on Windows are analogous. 아래 코드는 mermaid를 사용한 구현 예제입니다. 각 부분의 역할을 이해하면서 코드를 살펴보시기 바랍니다.

flowchart LR
  subgraph cause[Causes]
    N[Null deref]
    D[Dangling]
    S[Stack overflow]
    B[Buffer overrun]
    C[Bad cast]
  end
  subgraph debug[Tools]
    G[GDB/LLDB]
    A[ASan]
  end
  cause --> debug

---

Table of contents

1. What is a segfault?
2. Cause 1: null pointer
3. Cause 2: dangling / use-after-free
4. Cause 3: stack overflow
5. Cause 4: buffer overrun
6. Cause 5: bad cast
7. GDB/LLDB core analysis
8. AddressSanitizer

---

1. What is a segfault?

The kernel maps valid virtual pages for your process. Access outside that (null, freed storage, guard pages, wrong permissions) can trigger a CPU fault → SIGSEGV. Message:

Segmentation fault (core dumped)

core dumped (when enabled) writes a core file you can open in a debugger.

2. Null dereference

int* p = nullptr;
*p = 42;

Mitigation: check nullptr, use std::optional, design APIs that avoid bare pointers.

3. Dangling pointer / UAF

Returning a pointer to a stack array, or using memory after delete, yields undefined behavior—often a crash. Prefer std::vector, std::unique_ptr, std::string.

4. Stack overflow

Infinite recursion or huge stack arrays exhaust the stack. Fix: base cases, std::vector on the heap, iterative algorithms.

5. Buffer overrun

Raw arrays have no bounds checks; writing past the end can corrupt metadata or hit guard pages. Use std::vector::at, careful loop bounds, ASan.

6. Bad downcast

static_cast to derived when the object is not actually derived → corrupt vtables / reads → crash. Prefer dynamic_cast for polymorphic types when needed, and check nullptr.

7. GDB / LLDB cores

ulimit -c unlimited
./your_program   # crashes
gdb ./your_program core

Useful commands: bt, bt full, frame N, print ptr, info locals. LLDB: lldb -c core ./your_program.

8. AddressSanitizer

g++ -g -fsanitize=address test.cpp -o test
./test

Typical output includes exact source lines for heap-buffer-overflow, stack-buffer-overflow, heap-use-after-free, etc. CMake:

target_compile_options(myapp PRIVATE -fsanitize=address -g)
target_link_options(myapp PRIVATE -fsanitize=address)

---

Quick checklist

Symptom	Clue	Mitigation
Null	p == 0 in debugger	Checks / optional
Dangling	ASan UAF	Smart pointers
Stack	Deep bt repeats	Heap / iteration
Overrun	ASan overflow	Bounds / at()
Bad cast	Wrong type path	dynamic_cast

---

Related posts (internal)

• GDB/LLDB guide
• Sanitizers
• LNK2019

---

Keywords

Segmentation fault, segfault, SIGSEGV, core dump, GDB, AddressSanitizer, use-after-free

Closing: combine cores + debugger for post-mortems and ASan during development to catch invalid access before it ships. Search: segfault, C++ null pointer, GDB backtrace, ASan heap-use-after-free
