[2026] C++ Linking Explained: Static vs Dynamic Libraries, Symbols, and LTO

Introduction

Linking combines object files (.o) into an executable or library—the last stage of the build. The compiler turns each .cpp into machine code independently; the linker connects them into the final image.

1. Linking basics

Compile vs link

아래 코드는 bash를 사용한 구현 예제입니다. 코드를 직접 실행해보면서 동작을 확인해보세요.

# 1) Compile only (no link)
g++ -c main.cpp -o main.o
g++ -c util.cpp -o util.o
# 2) Link objects into executable
g++ main.o util.o -o myapp
# Or one step (compile + link)
g++ main.cpp util.cpp -o myapp

Layout: 다음은 cpp를 활용한 상세한 구현 코드입니다. 필요한 모듈을 import하고. 각 부분의 역할을 이해하면서 코드를 살펴보시기 바랍니다.

// util.h
#pragma once
int add(int a, int b);
// util.cpp
#include "util.h"
int add(int a, int b) {
    return a + b;
}
// main.cpp
#include <iostream>
#include "util.h"
int main() {
    std::cout << add(10, 20) << std::endl;
    return 0;
}

What the linker does

1. Symbol resolution — connect call sites to definitions
2. Relocation — fix addresses/offsets for the final layout
3. Final image — produce executable or .so/.dll

---

2. Static linking

Building a static library

g++ -c lib.cpp -o lib.o
ar rcs libmylib.a lib.o
g++ main.cpp -L. -lmylib -o myapp

Traits:

• Simple deployment (single binary option)
• No runtime library load
• Larger binary
• Library updates require relink

---

3. Dynamic linking

Linux/macOS shared libraries

아래 코드는 bash를 사용한 구현 예제입니다. 코드를 직접 실행해보면서 동작을 확인해보세요.

g++ -fPIC -c lib.cpp -o lib.o
g++ -shared lib.o -o libmylib.so
g++ main.cpp -L. -lmylib -Wl,-rpath,. -o myapp
./myapp
# Or use LD_LIBRARY_PATH
LD_LIBRARY_PATH=. ./myapp

Windows DLL (conceptual)

g++ -shared lib.cpp -o mylib.dll
g++ main.cpp -L. -lmylib -o myapp.exe

Traits:

• Smaller binaries; shared memory across processes
• Runtime loader must find the library
• Versioning and deployment are trickier

---

4. Common problems

Problem 1: undefined reference

undefined reference to `add(int, int)'

Fix: add the .o/.cpp or -l library that defines the symbol.

Problem 2: Library order

Dependencies go after dependents on many Unix linkers:

g++ main.o -lA -lB   # if main needs A and A needs B, order may matter

Problem 3: Library search path

g++ main.o -L./lib -lmylib -o myapp

Problem 4: Shared library not found at run time

g++ main.o -L./lib -lmylib -Wl,-rpath,./lib -o myapp
# or LD_LIBRARY_PATH, or install to system lib path + ldconfig

---

5. Inspecting symbols

nm

Lists symbols in objects or executables. T = defined in text, U = undefined.

ldd (Linux)

Lists shared library dependencies of an executable.

objdump

Disassembly (-d), symbol tables (-t), dynamic symbols (-T).

6. Link-time optimization (LTO)

g++ -flto main.cpp util.cpp -o myapp
g++ -flto -O3 main.cpp util.cpp -o myapp

Effects: whole-program optimization across TUs; longer builds; harder debugging.

7. Build examples

Makefile (sketch)

아래 코드는 makefile를 사용한 구현 예제입니다. 코드를 직접 실행해보면서 동작을 확인해보세요.

CXX = g++
CXXFLAGS = -std=c++17 -Wall -g
OBJS = main.o util.o
myapp: $(OBJS)
	$(CXX) $(OBJS) -o myapp

CMake (sketch)

add_library(mylib STATIC lib.cpp)
add_executable(myapp main.cpp util.cpp)
target_link_libraries(myapp mylib)

---

Summary

1. Linking joins object files.
2. Static bundles code; dynamic references shared libs.
3. Symbol resolution matches calls to definitions.
4. LTO can improve performance at build cost.

Static vs dynamic

	Static	Dynamic
Files	.a / .lib	.so / .dll
Size	Larger exe	Smaller exe
Speed	No load step	Load at startup
Updates	Relink	Often replace .so only
Next: Name mangling, Compilation process, Makefile.

---
